Name: GravityMain

Display Field: ENABLED

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description:

Service Item Id: b79f055f42c44e3ba4cb6002cab75d84

Copyright Text:

Default Visibility: true

MaxRecordCount: 10000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 11000.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 245803.72340638936
YMin: 190699.4794076383
XMax: 295975.61190755665
YMax: 230299.80112548172
Spatial Reference: 103436  (8150)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: SUBTYPE
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
N/A
Default Label: N/A
UniqueValueInfos:
• Value: 1
  Label: Collector
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [0, 0, 0, 255]
  Width: 7
• Value: 2
  Label: Interceptor
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [0, 0, 0, 255]
  Width: 8
• Value: 3
  Label: Siphon
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [56, 168, 0, 255]
  Width: 1
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: SubType

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• ENABLED ( type: esriFieldTypeSmallInteger, alias: Enabled , Coded Values: [0: False] , [1: True] )
• ADMINISTRATIVEAREA ( type: esriFieldTypeString, alias: AdministrativeArea, length: 30 , Coded Values: [East: East Side of Wisconsin River] , [West: West Side of Wisconsin River] )
• FACILITYID ( type: esriFieldTypeString, alias: FacilityID, length: 24 )
• INSTALLDATE ( type: esriFieldTypeDate, alias: InstallDate, length: 8 )
• LIFECYCLESTATUS ( type: esriFieldTypeString, alias: LifeCycleStatus, length: 10 , Coded Values: [ABANDONED: Abandoned] , [ACTIVE: Active] , [PROPOSED: Proposed] , ...1 more... )
• SUBTYPE ( type: esriFieldTypeInteger, alias: SubType )
• ELEVATION ( type: esriFieldTypeDouble, alias: Elevation , Range: [500, 1700] )
• DATASOURCE ( type: esriFieldTypeString, alias: DataSource, length: 24 , Coded Values: [ACAD1: ACAD1] , [Aerometric1990: Aerometric1990] , [Aerometric2000: Aerometric2000] , ...6 more... )
• DRAWINGREFERENCE ( type: esriFieldTypeString, alias: DrawingReference, length: 12 )
• LOCATIONDESCRIPTION ( type: esriFieldTypeString, alias: LocationDescription, length: 60 )
• DIAMETER ( type: esriFieldTypeDouble, alias: Diameter )
• MATERIAL ( type: esriFieldTypeString, alias: Material, length: 60 )
• SLOPE ( type: esriFieldTypeDouble, alias: Slope )
• REHABSTATUS ( type: esriFieldTypeString, alias: RehabStatus, length: 30 , Coded Values: [PE: Slip Lined with Poly Ethylene] , [PVC: Slip Lined with Polyvinyl Chloride] , [NONE: No rehab/original pipe] , ...1 more... )
• PIPESHAPE ( type: esriFieldTypeString, alias: PipeShape, length: 12 , Coded Values: [ROUND: Round] , [RECTANGULAR: Rectanular] , [ELLIPTICAL: Elliptical] , ...2 more... )
• UPSTREAMELEVATION ( type: esriFieldTypeDouble, alias: UpStreamElevation )
• DOWNSTREAMELEVATION ( type: esriFieldTypeDouble, alias: DownStreamElevation )
• FLOWDISTRICT ( type: esriFieldTypeInteger, alias: FlowDistrict , Coded Values: [1: Sanitary District 1] , [2: Sanitary District 2] , [3: Sanitary District 3] , ...32 more... )
• INSPECTDATE ( type: esriFieldTypeDate, alias: InspectDate, length: 8 )
• UPSTREAMMH ( type: esriFieldTypeString, alias: UpStreamMH, length: 20 )
• DOWNSRTREAMMH ( type: esriFieldTypeString, alias: DownStreamMH, length: 20 )
• REHABDATE ( type: esriFieldTypeDate, alias: RehabDate, length: 8 )
• OWNER ( type: esriFieldTypeString, alias: OWNER, length: 20 , Coded Values: [Private: Private] , [Wausau Water Works: WWW] )
• created_user ( type: esriFieldTypeString, alias: created_user, length: 255 )
• created_date ( type: esriFieldTypeDate, alias: created_date, length: 8 )
• last_edited_user ( type: esriFieldTypeString, alias: last_edited_user, length: 255 )
• last_edited_date ( type: esriFieldTypeDate, alias: last_edited_date, length: 8 )
• GlobalID ( type: esriFieldTypeGlobalID, alias: GlobalID, length: 38 )
• SHAPE ( type: esriFieldTypeGeometry, alias: Shape )
• SHAPE.STLength() ( type: esriFieldTypeDouble, alias: SHAPE.STLength() )
• NOTES ( type: esriFieldTypeString, alias: NOTES, length: 100 )

Types:

ID: 2
Name: Interceptor
Domains:
• ENABLED:
  Inherited
• ADMINISTRATIVEAREA:
  Inherited
• LIFECYCLESTATUS:
  Inherited
• SUBTYPE:
  Coded Values: [1: Collector] , [2: Interceptor]
• ELEVATION:
  Inherited
• DATASOURCE:
  Inherited
• DIAMETER:
  Coded Values: [15: 15"] , [18: 18"] , [20: 20"] , ...7 more...
• MATERIAL:
  Coded Values: [CONCRETE: Concrete] , [CLAY: Clay] , [PVC: Polyvinyl Chloride] , ...7 more...
• REHABSTATUS:
  Inherited
• PIPESHAPE:
  Inherited
• FLOWDISTRICT:
  Inherited

---

ID: 1
Name: Collector
Domains:
• ENABLED:
  Inherited
• ADMINISTRATIVEAREA:
  Inherited
• LIFECYCLESTATUS:
  Inherited
• SUBTYPE:
  Coded Values: [1: Collector] , [2: Interceptor]
• ELEVATION:
  Inherited
• DATASOURCE:
  Inherited
• DIAMETER:
  Coded Values: [4: 4"] , [6: 6"] , [7: 7"] , ...17 more...
• MATERIAL:
  Coded Values: [CONCRETE: Concrete] , [CLAY: Clay] , [RCP: Reinforced Concrete Pipe] , ...7 more...
• REHABSTATUS:
  Inherited
• PIPESHAPE:
  Inherited
• FLOWDISTRICT:
  Inherited
• OWNER:
  Inherited

---

ID: 3
Name: Siphon
Domains:
• ENABLED:
  Inherited
• ADMINISTRATIVEAREA:
  Inherited
• LIFECYCLESTATUS:
  Inherited
• ELEVATION:
  Inherited
• DATASOURCE:
  Inherited
• REHABSTATUS:
  Inherited
• PIPESHAPE:
  Inherited
• FLOWDISTRICT:
  Inherited
• OWNER:
  Inherited

---

Relationships:

• sMaintenanceTable (23) -- Related To: sMaintenanceTable (37)
• sRemarks (24) -- Related To: sRemarks (41)
• Annotation (6) -- Related To: Gravity Main Size Anno (20)
• sTVSurvey (25) -- Related To: sTVSurvey (39)
• Document (26) -- Related To: sDocumentLinkTable (40)

Supported Operations:   Query   Query Attachments   Query Analytic   Query Related Records   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
