Name: sLateral

Display Field: STREETNAME

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: 182.0175(2m)(2m)  Transmission facilities owner requirements.(a) Responsibilities. A transmission facilities owner shall do all of the following:1. Respond to a planning notice within 10 days after receipt of the notice by conducting field markings, providing records and taking other appropriate responses.2. Respond to an excavation notice within 3 working days by marking the location of transmission facilities and, if applicable, laterals as provided under par. (b) in the area described in the excavation notice.3. Provide emergency locater service within 24 hours after receiving a request for that service.(b) Facilities marking. A person owning transmission facilities, upon receipt of an excavation notice, shall mark in a reasonable manner the locations of transmission facilities at the area described in the notice to enable the excavator to locate the transmission facilities without endangering the security of the facilities or the public. For purposes of this paragraph, transmission facilities are marked in a reasonable manner if the owner of the transmission facilities locates and marks the transmission facilities to a level of accuracy and precision consistent with national standards. Except as provided in par. (bm), if the person is a local governmental unit and if the excavation notice relates to sewer or water facilities owned by the local governmental unit, the local governmental unit shall also mark the locations within the public right-of-way of all laterals connected to the sewer or water facilities at the area described in the notice. The marking of facilities shall be completed within 3 working days after receipt of the notice, or if notice is given more than 10 days before excavation is scheduled to begin, marking shall be completed at least 3 working days before excavation is scheduled to begin. If the approximate location of a transmission facility is marked with paint, flags, stakes or other physical means, the following color coding of lines, cables or conduits shall comply with the uniform color code adopted by the American National Standards Institute:1. Electric power: red.2. Gas, oil, steam, petroleum or gaseous materials: yellow.3. Communications, cable television or alarm or signal systems: orange.4. Water, irrigation or slurry systems: blue.5. Sewer or drain systems: green.6. Temporary survey markings: pink.7. Proposed excavation: white.(bm) Local governmental units. A local governmental unit is considered to have satisfied the requirement under par. (b) to mark the locations within the public right-of-way of all laterals connected to sewer or water facilities if the local governmental unit makes available to an excavator, for inspection and making copies, information on the location of such laterals as shown on maps, drawings, diagrams, or other records, that are readily available. If a local governmental unit has no such readily available information regarding such laterals and the local governmental unit provides the excavator with a written notice that the local governmental unit has no such readily available information, the local governmental unit is considered to have satisfied the requirement under par. (b) to mark the locations within the public right-of-way of all laterals connected to the sewer or water facilities.(br) Private transmission facilities. Paragraphs (a) to (bm) do not apply to owners of private transmission facilities.(c) Facilities inspection and repair. Every person owning transmission facilities who receives a notice of possible damage shall inspect the facilities for damage within 6 hours after receipt of the notice if there is risk of personal injury or loss of life or within 24 hours after receipt of the notice if there is not a risk of personal injury or loss of life and shall repair any damage found as soon as practicable. Unless the owner of any transmission facility is notified or has knowledge of damage to transmission facilities by an excavator, the owner is not responsible for or required to make an inspection of its transmission facilities, nor shall the owner, in the absence of notification or knowledge, be responsible for supervising in any manner the excavation.(2r)  Facilities installed after December 31, 2006. Any person who, after December 31, 2006, installs a nonconductive water or sewer lateral shall also install a locating wire or other equally effective means for marking the location of the lateral. The requirement shall not apply to minor repairs to, or partial replacements of, laterals installed before January 1, 2007.

Service Item Id: 58d8c360c1814a0fa3840745a3cd957f

Copyright Text:

Default Visibility: true

MaxRecordCount: 10000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -9992794.589994373
YMin: 5610309.844028684
XMax: -9971346.798110947
YMax: 5622259.07891373
Spatial Reference: 102100  (3857)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSSolid
Color: [76, 230, 0, 255]
Width: 1
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: false

HasM: false

Has Attachments: true

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: SubType

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• ENABLED ( type: esriFieldTypeSmallInteger, alias: Enabled , Coded Values: [0: False] , [1: True] )
• ADMINISTRATIVEAREA ( type: esriFieldTypeString, alias: AdministrativeArea, length: 30 , Coded Values: [East: East Side of Wisconsin River] , [West: West Side of Wisconsin River] )
• FACILITYID ( type: esriFieldTypeString, alias: FacilityID, length: 24 )
• INSTALLDATE ( type: esriFieldTypeDate, alias: InstallDate, length: 8 )
• LIFECYCLESTATUS ( type: esriFieldTypeString, alias: LifeCycleStatus, length: 10 , Coded Values: [ABANDONED: Abandoned] , [ACTIVE: Active] , [PROPOSED: Proposed] , ...1 more... )
• SUBTYPE ( type: esriFieldTypeInteger, alias: SubType )
• ELEVATION ( type: esriFieldTypeDouble, alias: Elevation , Range: [500, 1700] )
• DATASOURCE ( type: esriFieldTypeString, alias: DataSource, length: 24 , Coded Values: [ACAD1: ACAD1] , [Aerometric1990: Aerometric1990] , [Aerometric2000: Aerometric2000] , ...6 more... )
• DRAWINGREFERENCE ( type: esriFieldTypeString, alias: DrawingReference, length: 25 )
• LOCATIONDESCRIPTION ( type: esriFieldTypeString, alias: LocationDescription, length: 60 )
• OWNER ( type: esriFieldTypeString, alias: Owner, length: 20 )
• STREETNUMBER ( type: esriFieldTypeInteger, alias: StreetNumber )
• STREETDIRECTION ( type: esriFieldTypeString, alias: StreetDirection, length: 2 , Coded Values: [N: N] , [S: S] , [E: E] , ...1 more... )
• STREETNAME ( type: esriFieldTypeString, alias: StreetName, length: 20 , Coded Values: [ADAMS: ADAMS] , [ADOLPH: ADOLPH] , [ADRIAN: ADRIAN] , ...573 more... )
• STREETDESIGNATION ( type: esriFieldTypeString, alias: StreetDesignation, length: 4 , Coded Values: [Av: Avenue] , [Blvd: Boulevard] , [Cir: Circle] , ...13 more... )
• LATERALTYPE ( type: esriFieldTypeString, alias: LateralType, length: 10 , Coded Values: [Domestic: Domestic] , [Commercial: Commercial] , [Industrial: Industrial] , ...1 more... )
• PLUMBER ( type: esriFieldTypeString, alias: Plumber, length: 50 )
• PIN ( type: esriFieldTypeString, alias: PIN, length: 17 )
• INSPECTDATE ( type: esriFieldTypeDate, alias: InspectDate, length: 8 )
• created_user ( type: esriFieldTypeString, alias: created_user, length: 255 )
• created_date ( type: esriFieldTypeDate, alias: created_date, length: 8 )
• last_edited_user ( type: esriFieldTypeString, alias: last_edited_user, length: 255 )
• last_edited_date ( type: esriFieldTypeDate, alias: last_edited_date, length: 8 )
• GlobalID ( type: esriFieldTypeGlobalID, alias: GlobalID, length: 38 )
• SHAPE ( type: esriFieldTypeGeometry, alias: Shape )
• ServiceLength ( type: esriFieldTypeDouble, alias: ServiceLength )
• NOTES ( type: esriFieldTypeString, alias: NOTES, length: 100 )
• SHAPE.STLength() ( type: esriFieldTypeDouble, alias: SHAPE.STLength() )
• CUST_ROW_DIAMETER ( type: esriFieldTypeDouble, alias: Customer ROW Diameter , Coded Values: [3: 3"] , [4: 4"] , [6: 6"] , ...4 more... )
• CUST_ROW_MATERIAL ( type: esriFieldTypeString, alias: Customer ROW Material, length: 60 , Coded Values: [CIP: Cast Iron] , [CONCRETE: Concrete] , [DUCTILE IRON PIPE: Ductile Iron Pipe] , ...7 more... )

Types:

ID: 1
Name: Lateral
Domains:
• ENABLED:
  Inherited
• ADMINISTRATIVEAREA:
  Inherited
• LIFECYCLESTATUS:
  Inherited
• SUBTYPE:
  Coded Values: [1: Lateral]
• ELEVATION:
  Inherited
• DATASOURCE:
  Inherited
• CUST_ROW_DIAMETER:
  Inherited
• CUST_ROW_MATERIAL:
  Inherited
• STREETDIRECTION:
  Coded Values: [N: North] , [S: South] , [E: East] , ...1 more...
• STREETNAME:
  Inherited
• STREETDESIGNATION:
  Coded Values: [Av: Avenue] , [Blvd: Boulevard] , [Ctr: Center] , ...14 more...
• LATERALTYPE:
  Inherited

---

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
